GA15 1-1/2'' Metallic (Aluminum & Cast Iron) Diaphragm Pump
Ratio:1:1
Maximum Flow gpm (lpm):90 (340.7)
Displacement per cycle gal (l):.64 (2.42)
Air Inlet (Female):1/2-14 NPTF-1
Fluid Inlet/Outlet:1-1/2 11-1/2 N.P.T.F. - 1
Rp 1-1/2 (1-1/2 - 11 BSP parallel)
Max. operating pressure psi (bar):120-psi (8.3-bar)
Suspended solids max. dia in (mm):1/4-inch (6.4-mm)
Weight (kg):Aluminum: 23.4 / Stainless Steel: 38.3 / Cast iron: 36.1
Maximum dry suction lift ft (m):ft (m) 19 (5.8)
Muffler:Included
View or Download BrochureOnline Inquiry
Description
A Series 1-1/2" metallic diaphragm pumps achieve flow rates of up to 90 GPM (340.7 LPM) and offer a wide array of material and porting configurations. These pumps are often used for transfer, filling, recirculation and batching in Paint, Oil & Gas, Mining, Construction, Chemical and Petrochemical markets.


GA15 1 1/2" Aluminum & Cast Iron Diaphragm Pump

Accessories

  • A637118-C Air Section Service Kit

  • A637124-XX Fluid Section Service Kit

Pump Casing Materials

  • Aluminum

  • Cast Iron

Diaphragm Materials

  • Viton

  • PTFE w/ Santoprene backer

  • Hytrel

  • Santoprene

  • Nitrile

  • Neoprene

  • E.P.R.
