Main Performance Parameters

•Flowrate up to 2000L/H

•Pressure up to 12 bar

•Suction lift: up to 3 m water

•Maximum suction pressure: 2 bar

•Accuracy: ± 2% of rated flow from 10%  to 100% stroke

•Maximum temperature of pumped liquid: 40℃

Main Features

Liquid End

•Mechanical actuated diaphragm design

•Eliminate contour plates,easy for material pass

•PVC, PVDF & 316SS liquid end material

•High viscolity,slurry  application

•Self-cleaning suction/discharge check valve

Drive End

•Variable eccentric drive mechanism for smooth sinusoidal flow

•Rugged construction designed to withstand tough environments

•Hard-wearing ball bearings to make pump work more stably

•Oil bath lubrication for all of drive components

•Lockable micrometer stroke, adjustment can be adjusted while pump is running or stopped

Automatic Capacity Control Options

Electrical capacity controller: Accept external control signal to adjust the stroke length•

•Power supply: 220V-50Hz, single phase

•Input signal: 4-20mA analog signal

•Output signal: 4-20mA/1-5V analog signal for record display and control system

Variable frequency controller: Accept external control signal to adjust the stroke speed

•Power supply: 220V-50Hz, single phase / 380V-50Hz, three phase

•Input signal: 4-20mA analog signal

ON/OFF control the three phase motor to adjust the flowrate

•Power supply: 200-240V/50/60Hz, single phase

•Input signal: 4-20mA analog signal / pulse signal / manual
